OC Robotics to provide snake-arm robot demonstration for Sellafield Ltd

Company News Tuesday, July 5, 2011: OC Robotics

OC Robotics is pleased to announce the signing of a new contract to provide a snake-arm robot capability demonstration to Sellafield Ltd. This first-of-its-kind demonstration for Sellafield will include two snake-arms, deployed using OC Robotics’ Rail&RotateTM platform. The snake-arms will transport a range of end effectors into a purpose-built cell mock-up to demonstrate various decommissioning and inspection capabilities.

Both snake-arms will be variants of the OC Robotics Explorer Range. Each arm will have 22 degrees of freedom (DoF), will measure 2.5m long and 100mm in diameter, and will be remotely operated by joystick through OCRobotics’ bespoke user interface. The first snake-arm will deploy an OC Robotics 3 DoF wrist and gripper. The wrist and gripper will contain a navigation camera and variable lighting, as well as acting as a quick change tool interface with capability to carry electric and pneumatic tools with services fed through the centre of the snake-arm. A custom inspection camera, a swabbing tool, a representative radiological probe, and sampling scoops will all be demonstrated.

The second snake-arm will have a high-pressure water-jetting tool integrated into it. The tool is being supplied by Sellafield Ltd and is of a type currently used for decontamination tasks on their site. This will be an example of how snake-arm robots can be used as a transport mechanism for existing tooling within confined hazardous spaces.

Both arms will be deployed on OC Robotics’ innovative Rail&RotateTM delivery system. This will allow both snake-arms to nose-follow, snaking their way through a metre-thick access hole into the cell. The Rail&Rotate provides both vertical and horizontal entry, options for entering a cell through vertical and horizontal access holes.

OC Robotics will construct a cell mock-up to demonstrate these operations. The mock-up measures 5m x 3m x 2.5m high and is representative of confined-space challenges found in nuclear environments across the Sellafield site.

This is the first contract signed between OC Robotics and Sellafield Ltd where hardware will be used. The hardware will provide demonstrations for Sellafield employees both at OC Robotics and potentially at Sellafield premises and will feature as a centre-piece for OC Robotics’ future open days.

Rob Buckingham, managing director at OC Robotics, stated that “This is an exciting development for OC Robotics. Previously we have built bespoke snake-arm solutions for very specific problems. The objective with this work is to demonstrate that snake-arm robots can become a generic, modular tool for a wide range of decommissioning tasks. This offers company’s like Sellafield the ability to standardise on a single platform and develop the experience and expertise required to solve confined space challenges.”

Initial concepts: snake-arm reaching into cell (Top Left), cell mockup (Bottom Left), wrist and gripper (Top Right), gripper holding swabbing tool (Centre Right), gripper holding inspection camera (Bottom Right)OC Robotics has been developing snake-arm robots for 10 years. The exceptional ability of snake-arm robots to manoeuvre into otherwise inaccessible spaces makes them valuable in a large number of applications in high-value industrial markets. OC Robotics has delivered robots and has provided consultancy and analysis for wide-ranging industries including nuclear, aerospace and security. In addition to its commercial success, OC Robotics has won several awards including the Queen’s Award for Enterprise in 2009.
